SGA-2286Z RF Micro Devices SGA-2286Z label picture SGA-2286Z real image SGA-2286Z real image 2
Same model may have multiple batches, images only for reference.
SGA-2286Z RF Micro Devices SGA-2286Z label picture SGA-2286Z real image SGA-2286Z real image 2
SGA-2286Z RF Micro Devices SGA-2286Z label picture SGA-2286Z real image SGA-2286Z real image 2
Same model may have multiple batches, images only for reference.

SGA-2286Z

Part No SGA-2286Z
Manufacturer RF Micro Devices
Catalog RF Amplifiers
Description IC AMP HBT SIGE 5000MHZ SOT-86 / RF Amp Single Cascadable Amp 5GHz 2.5V 4-Pin SOT-86 T/R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer RF Micro Devices
Packaging Reel - TR
Status Obsolete(EOL)
Frequency 0Hz to 5GHz
P1dB 7dBm (5mW)
Gain 14dB
Noise Figure 3.5dB
RF Type Cellular, GSM, PCS, UMTS
Supply Voltage - Operating 1.9 V to 2.5 V
Operating Supply Current 17mA to 23mA
Test Frequency 1.95GHz
Case / Package SOT-86
Win Source Part Number 028295-SGA-2286Z
Popularity Medium
Supply and Demand Status Balance
Family Name SGA-2286
Introduction Date October 01, 2008
ECCN 5A991.g
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian SGA-2286Z CAD Model

Description

The RF Micro Devices 028295-SGA-2286Z is an obsolete (EOL) electronic component that is no longer available in the market.

  • Applications: Cellular, GSM, PCS, and UMTS
  • Gain: 14dB
  • Noise Figure: 3.5dB
  • P1dB: 7dBm (5mW)
  • Supply Voltage Range: 1.9V to 2.5V
  • Operating Supply Current: 17mA to 23mA
