Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Pulse Electronics Corporation
Packaging Reel - TR
Status Active
Frequency Group UHF (300 MHz to 1 GHz), UHF (1 GHz to 2 GHz)
Frequency (Center/Band) 850MHz, 1.9GHz
Frequency Range 869MHz to 894MHz, 1.93GHz to 1.99GHz
Antenna Type Chip
Number of Bands 2
Termination Solder
Mounting SMD (SMT)
Height (Max) 0.118" (3.00mm)
Applications GSM
Win Source Part Number 213936-W3047A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name W3047A
Introduction Date December 28, 2009
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian W3047A CAD Model

Description

The W3047A from Pulse Electronics Corporation is an active electronic component suitable for use in GSM applications.

  • Application: GSM
  • Popularity: High
  • Supply and Demand Status: Balanced
  • Counterfeit Risk: Low
  • Antenna Type: Chip
