The VN5E016AFHTR-E is a robust high-side driver manufactured by STMicroelectronics, designed to deliver outstanding performance in driving inductive, capacitive, and resistive loads. This device is particularly suitable for automotive applications and is capable of driving a wide range of loads, including lamps, solenoids, and motors.

Key Features

• High-Side Switch: The VN5E016AFHTR-E operates as a high-side switch, allowing for easy control of the power supply to the load.
• Current Control: This device includes current sensing and embedded current control, ensuring precise management of the load current.
• Thermal Protection: It is equipped with over-temperature protection, which safeguards the device and the load from damage due to excessive heat.
• Wide Supply Voltage Range: The VN5E016AFHTR-E can handle a broad range of supply voltages, making it versatile for various automotive electrical systems.
• Diagnostic Functions: Integrated diagnostic functions provide feedback on the status of the device and the system, enabling fault detection and system management.

Applications

The VN5E016AFHTR-E is ideal for a variety of applications within the automotive sector, including:

• Automotive lighting systems
• Engine control units
• Body control modules
• Smart junction boxes

Quality and Reliability

STMicroelectronics ensures that the VN5E016AFHTR-E meets the highest quality and reliability standards, which are critical for automotive applications. The device is designed to withstand harsh environments and is compliant with automotive industry regulations.

Product Availability

The VN5E016AFHTR-E is available in a compact and efficient HSSOP24 package, which is suitable for space-constrained applications. It is also provided in tape and reel packaging, facilitating the manufacturing process for high-volume production.

For more detailed information, including datasheets, technical specifications, and application notes, visit the STMicroelectronics website or contact their customer support team.
