Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Logic Type Complementary Pair Plus Inverter
Supply Voltage 3 V to 18 V
Number of Bits 3
Temperature Range - Operating -55°C to 125°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Win Source Part Number 022551-MC14007UBDR2G
Ultra Librarian 3D Model Ultra Librarian MC14007UBDR2G CAD Model

Description

ON Semiconductor MC14007UBDR2G Dual Complementary Pair Plus Inverter

The ON Semiconductor MC14007UBDR2G is a versatile and high-performance integrated circuit that belongs to the family of CMOS logic ICs. This dual complementary pair plus inverter is designed to offer reliable logic operations in a broad range of electronic applications, from simple logic gates to more complex digital systems. The device features two pairs of complementary MOS transistors and an additional inverter, providing designers with the flexibility to implement various logic functions such as buffers, inverters, and gates.

Constructed with ON Semiconductor's advanced CMOS technology, the MC14007UBDR2G ensures low power consumption while maintaining high noise immunity and a wide operating voltage range. This makes it an ideal choice for battery-operated devices and power-sensitive applications. The IC operates over a voltage range of 3V to 18V, providing ample margin for stable operation under varying supply conditions.

The package of the MC14007UBDR2G is the SOIC-14 (Small Outline Integrated Circuit), which is a surface-mount package that allows for a compact footprint on printed circuit boards (PCBs). This space-saving design is particularly beneficial for modern electronic devices where board space is at a premium.

Key features of the MC14007UBDR2G include:

  • Low power consumption: Ideal for battery-powered and energy-efficient designs.
  • Wide operating voltage range: 3V to 18V, accommodating various power supply specifications.
  • High noise immunity: Ensures stable operation in electrically noisy environments.
  • Complementary MOS transistor pairs: Provides flexibility in implementing a wide range of logic functions.
  • Additional inverter: Expands the functionality and application possibilities of the IC.
  • SOIC-14 packaging: Offers a compact solution for space-constrained applications.

With its robust performance and flexible design, the ON Semiconductor MC14007UBDR2G is a valuable component for designers looking to create efficient and reliable digital systems. Whether used in consumer electronics, automotive modules, or industrial controls, this dual complementary pair plus inverter stands out as a smart choice for a multitude of logic applications.
