Categories Discrete Semiconductor Products
Estimated Pruduction Lead Time 27 Weeks
Features Diode Schottky 120 V 15A Surface Mount TO-277-3
Manufacturer ON Semiconductor
Package Reel - TR
Speed Fast Recovery =< 500ns, > 200mA (Io)
Mounting Surface Mount
Package TO-277, 3-PowerDFN
Case / Package TO-277-3
Family Name FSV15120
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Other Part Number FSV15120VCT, FSV15120VDKR, FSV15120VTR
Quantity per package 5000
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 872344-FSV15120V
Ultra Librarian 3D Model Ultra Librarian FSV15120V CAD Model

Description

Introducing the FSV15120V Power Rectifier by ON Semiconductor

ON Semiconductor, a renowned leader in energy-efficient innovations, presents the FSV15120V, a state-of-the-art Schottky Barrier Rectifier designed to meet the demanding requirements of modern electronic applications. This high-performance power rectifier is specifically engineered for use in power supply circuits, offering a combination of low forward voltage drop and high current handling capability.

Optimized for Efficiency

The FSV15120V is optimized for high efficiency, making it an ideal choice for applications where power loss needs to be minimized. With its Schottky Barrier design, this diode provides a very low forward voltage drop (Vf), which significantly reduces conduction losses and improves overall system efficiency. This characteristic is particularly beneficial in applications such as switch-mode power supplies (SMPS), where efficiency is crucial.

Robust and Reliable

Reliability is at the core of the FSV15120V's design. It boasts a high surge current capability, ensuring it can handle the rigors of applications prone to surges and spikes without compromising its integrity. This makes the FSV15120V suitable for high-reliability environments where consistent performance is a must.

Key Features

  • Voltage Rating: The device has a maximum repetitive reverse voltage (Vrrm) of 120V, making it suitable for a wide range of applications.
  • Current Capacity: It can conduct up to 15A of continuous forward current (If), which is impressive for its compact size.
  • Thermal Performance: The FSV15120V is capable of operating within a wide temperature range, ensuring stability and performance even under extreme conditions.
  • Package: Housed in a robust and compact TO-220F package, the FSV15120V ensures a minimal footprint on PCBs, while providing excellent thermal conduction properties.

Applications

The versatile nature of the FSV15120V allows it to be used in a variety of applications, including:

  • Power supply management
  • DC-DC converters
  • Free-wheeling diodes in converters and motor control circuits
  • Automotive applications

With ON Semiconductor's commitment to quality, the FSV15120V is a perfect choice for designers looking for a robust, efficient, and reliable power rectifier solution. Its combination of low power loss, high surge capability, and compact form factor make it a valuable component in any power management system.
