Products specifications

Categories Integrated Circuits
Manufacturer NXP
Packaging Reel - TR
Status Obsolete(EOL)
Type Video Decoder
Applications Desktop, Processing, Video
Analog Supply Voltage 3.1 V to 3.5 V
Digital Supply Voltage 3 V to 3.6 V
Mounting SMD (SMT)
Case / Package 156-LBGA (15x15)
Win Source Part Number 063979-SAA7114E/V2
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SAA7114E/V2 CAD Model

Description

The NXP SAA7114E/V2 is a highly integrated video decoder that is designed to facilitate the conversion of analog video signals into digital form for multimedia applications. This advanced chip is capable of processing signals from a variety of analog sources such as VCRs, DVD players, and surveillance cameras, making it an ideal solution for use in digital video systems, video capture cards, and any application requiring a bridge between analog video and digital processing.

Key Features

  • Multi-Standard Support: The SAA7114E/V2 supports a wide range of video standards, including PAL, NTSC, and SECAM. This versatility ensures that the decoder can be used in different regions without compatibility issues.
  • High-Quality Video Decoding: With its advanced 10-bit A/D conversion and 5-line adaptive comb filter, the decoder delivers high-quality video output, ensuring clear and crisp images.
  • Multiple Input Channels: The device offers several analog inputs, enabling it to handle up to four CVBS or two S-Video (Y/C) sources. This flexibility allows for the easy integration of multiple video sources.
  • Programmable Video Output Formats: The SAA7114E/V2 provides a range of output formats including ITU-R BT.656 and digital YUV, which can be easily interfaced with various digital video processors or SoCs.
  • Integrated Scaler and Flicker Filter: The chip includes an on-chip scaler and flicker filter to optimize the video output for specific display requirements.

Applications

The SAA7114E/V2 is well-suited for a wide array of applications, including:

  • PC-based video capture and conferencing
  • Set-top boxes and digital video recorders (DVRs)
  • Security and surveillance systems
  • Video conferencing systems
  • Automotive and in-vehicle video systems

Technical Specifications

The SAA7114E/V2 operates on a 3.3V power supply and is available in a 64-pin QFP package. Its operating temperature range is from -40°C to +85°C, ensuring reliable performance across diverse environments.

For developers and system integrators looking for a robust and flexible video decoding solution, the NXP SAA7114E/V2 offers a compelling mix of features and performance, making it a go-to choice for high-quality analog-to-digital video conversion.
