Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer NXP
Packaging Tube
Core Processor HC08
Data Bus Width 8-Bit
Speed 8MHz
Peripherals LVD, POR, PWM
The number of I/O 13
Program Memory Size 4KB (4K x 8)
Program Memory Type FLASH
Date RAM Size 128 x 8
Supply Voltage 2.7V ~ 5.5V
Data Converters A/D 6x10b
Temperature Range - Operating -40°C ~ 125°C
Mounting Style SMD
Manufacturer Package 16-SOIC
Supplier Device Package 16-SOIC
Family Part Number MC908QY4
Manufacturer Pack Quantity 47
MSL Level 3 (168 Hours)
Win Source Part Number 1220396-MC908QY4AMDWE
Manufacturer Homepage www.freescale.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MC908QY4AMDWE CAD Model

Description

The NXP MC908QY4AMDWE is a versatile and powerful microcontroller that serves as an integral part of various embedded systems. This microcontroller is from the MC9S08 family, which is renowned for its high performance, reliability, and ease of use. The MC908QY4AMDWE is particularly well-suited for industrial applications, automotive control systems, and smart IoT devices.

Key Features

  • Core: This microcontroller features a HC08 core, which is a high-performance 8-bit architecture designed by NXP. The core is capable of executing most instructions in just a few clock cycles, providing efficient processing capabilities for complex tasks.
  • Memory: It comes equipped with 4KB of on-chip flash memory, which is ideal for storing firmware and applications. Additionally, it has 128 bytes of RAM for data processing and 256 bytes of EEPROM for non-volatile storage of configuration data.
  • Operating Voltage: The device operates at a voltage range of 2.7V to 5.5V, making it suitable for battery-powered and low-power applications.
  • I/O Pins: The MC908QY4AMDWE offers 21 general-purpose input/output (GPIO) pins, providing ample connectivity options for interfacing with sensors, actuators, and other peripherals.
  • Communication Interfaces: It includes a serial communication interface (SCI) for UART communication, allowing for easy integration with other microcontrollers and peripheral devices.
  • Analog-to-Digital Converter: An integrated 8-channel, 10-bit analog-to-digital converter (ADC) enables the microcontroller to process analog signals, which is essential for sensor-based applications.
  • Timers: Multiple timers, including an 8-bit modulo timer and a 16-bit timer/pulse-width modulator (PWM), provide precise timing and control for various applications.
  • Temperature Range: The device is designed to operate within a temperature range of -40°C to 85°C, ensuring reliable performance in harsh environmental conditions.

Applications

The MC908QY4AMDWE microcontroller is highly adaptable and can be used in a wide range of applications, including but not limited to:

  • Automotive control systems
  • Industrial automation
  • Smart home devices
  • Consumer electronics
  • Portable medical devices

With its robust set of features and NXP's commitment to quality, the MC908QY4AMDWE is an excellent choice for developers looking to create reliable and efficient embedded systems.
