77209C Real Image
Same model may have multiple batches, images only for reference.

77209C

Part No 77209C
Manufacturer Murata Power Solutions Inc.
Catalog HOT - SALES and EOL Components
Description PULSE XFMR 2:1:1 16.3MH
Datasheet
77209C Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Transformers
Manufacturer Murata Power Solutions Inc.
Packaging Tube
Transformer Type SCR and Triac Trigger (Encapsulated)
Inductance 16.3mH
ET (Volt-Time) 482VμS
Mounting Style Through Hole
Parts Dimension 1.000" L x 0.799" W (25.40mm x 20.30mm)
Height - Seated (Maximum) 0.484" (12.30mm)
Temperature Range - Operating 0°C ~ 70°C
Manufacturer Pack Quantity 25
MSL Level 1 (Unlimited)
Win Source Part Number 052873-77209C
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 77209C CAD Model

Description

Description

Built for high-performance applications, the 77209C features advanced technology to support complex electronic tasks. Its robust construction assures continuous operation even under demanding conditions.

Applications

  • Medical Devices
  • Automotive Electronics
  • Data Communication Systems

Features and Benefits

  • Advanced technology for superior performance.
  • Robust and reliable construction.
  • Compact size for versatile applications.

Additional Details

The 77209C is engineered to meet the needs of highly technical applications, combining efficiency with dependable performance for sophisticated projects.
