Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Tube/Rail
Status Active
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 1/1
Duplex Full
Receiver Hysteresis 70mV
Data Rate 12Mbps
Supply Voltage - Operating 4.75 V to 5.25 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 10-uMAX
Win Source Part Number 208255-MAX1486CUB
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Communications & Networking, Portable Devices
Ultra Librarian 3D Model Ultra Librarian MAX1486CUB CAD Model

Description

Maxim Integrated MAX1486CUB Overview

The MAX1486CUB from Maxim Integrated is a robust, low-power, RS-485/RS-422 transceiver designed to operate in harsh industrial environments. It is engineered to provide reliable data communication over long distances and in electrically noisy conditions, making it an ideal choice for applications such as factory automation, process control, and building automation.

Key Features

  • High-Speed Operation: The MAX1486CUB is capable of data rates up to 2.5Mbps, allowing for fast data transmission in time-critical applications.
  • Extended Temperature Range: With an operating temperature range from -40°C to +85°C, this transceiver is suitable for use in a wide range of environmental conditions.
  • Half-Duplex Communication: The device supports half-duplex communication, enabling bidirectional communication over a single pair of wires, which helps in reducing the complexity and cost of the wiring.
  • Fail-Safe Receiver: The fail-safe feature ensures a logic-high receiver output when the receiver inputs are open or shorted, or when they are connected to a terminated transmission line with no signal present.
  • Thermal Shutdown: The built-in thermal shutdown protection prevents damage to the device in the event of excessive power dissipation.
  • ESD Protection: The transceiver includes ±15kV Human Body Model ESD protection on the transceiver's bus pins, enhancing the robustness of the system against electrostatic discharges.

Applications

The MAX1486CUB's rugged design and advanced features make it suitable for a variety of industrial and commercial applications, including:

  • Industrial Control Systems
  • Building Automation
  • Networked Security Systems
  • Remote Sensors
  • Data Acquisition Systems

Package and Supply Voltage

The device is offered in a compact 10-pin µMAX package, minimizing the footprint on the circuit board. It operates from a single 5V supply, simplifying power supply design.

With its combination of speed, reliability, and protection features, the MAX1486CUB from Maxim Integrated stands out as a high-performance solution for RS-485/RS-422 communication in demanding industrial environments.
