Part No 0010897282
Manufacturer Molex, LLC
Catalog Rectangular Connectors
Description CONN HEADER VERT 28POS 2.54MM / Connector Header Through Hole 28 position 0.100" (2.54mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors>Headers, Male Pins
Manufacturer Molex
Packaging Bulk
Connector Type Header, Breakaway
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 28
Number of Rows 2
Row Spacing - Mating 0.100" (2.54mm)
Number of Positions Loaded All
Style Board to Board or Cable
Shrouding Unshrouded
Mounting Through Hole
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.240" (6.10mm)
Contact Length - Post 0.107" (2.71mm)
Overall Contact Length 0.437" (11.10mm)
Insulation Height 0.090" (2.29mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 15.0µin (0.38µm)
Contact Finish - Post Tin
Contact Material Copper Alloy
Insulation Material Liquid Crystal Polymer (LCP), Glass Filled
Material Flammability Rating UL94 V-0
Insulation Color Black
Contact Finish Thickness - Post 74.8µin (1.90µm)
Applications Automotive, General Purpose, Lighting, Medical, Telecommunications
Base Product Number 001089
RoHS Status ROHS3 Compliant
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Other Part Number 0010-89-7282-E,10897282-E,WM50012-7282,0010897282-E,10897282,WM50012-28,WM26828,0010-89-7282,10-89-7282,10-89-7282-E,WM26828-ND,WM50012-7282-ND
Standard Package 1
Win Source Part Number 1332991-0010897282
Ultra Librarian 3D Model Ultra Librarian 0010897282 CAD Model

Description

The Molex 28-pin male connector is a rectangular connector used for headers.

  • Header Type: Breakaway
  • Gender: Male Pins
  • Positions Loaded: All 28
  • Rows: Two
  • Termination: Solder
  • Fastening Type: Push-Pull
  • Contact Material: Copper Alloy
  • Voltage Rating: Not Specified
  • Mated Stacking Heights: Not Specified
  • Material Flammability Rating: UL94 V-0
  • Applications: Automotive, General Purpose, Lighting, Medical, and Telecommunications
  • Pitch-Mating: 0.100 inches (2.54mm)
  • Contact Finish-Mating: Gold
  • Contact Finish Thickness-Mating: 15.0µin (0.38µm)
  • Contact Finish-Post: Tin
  • Contact Finish Thickness-Post: 74.8µin (1.90µm)
  • Insulation Color: Black
  • Shrouding: Unshrouded
  • Row Spacing-Mating: 0.100 inches (2.54mm)
  • Contact Length-Post: 0.107 inches (2.71mm)
  • Overall Contact Length: 0.437 inches (11.10mm)
  • Insulation Height: 0.090 inches (2.29mm)
  • Contact Shape: Square
  • Temperature Range: Not Specified
  • Contact Length-Mating: 0.240 inches (6.10mm)
  • ECCN: EAR99
  • MSL Level: 1 (Unlimited)
  • HTSUS Code: 8536.69.4040
