Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Altera
Status Active
Number of LABs/CLBs 3022
Number of Logic Elements/Cells 60440
Total RAM Bits 2544192
Number of I/O 718
Supply Voltage - Operating 1.15 V to 1.25 V
Mounting SMD (SMT)
Temperature Range - Operating -40°C to 100°C (TJ)
Case / Package 1020-FBGA (33x33)
Win Source Part Number 015483-EP2S60F1020I4N
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name EP2S60
Introduction Date January 22, 2004
ECCN 3A001.a.7.a
Country of Origin Republic of Korea, Taiwan
Estimated EOL Date 2023
Ultra Librarian 3D Model Ultra Librarian EP2S60F1020I4N CAD Model

Description

Product Description

The EP2S60F1020I4N FPGA offers a high level of integration, combining strong processing abilities with superior I/O standards. Part of the Stratix II family, this product is tailored for applications requiring high efficiency and reliability.

Features and Benefits

  • High Integration Level: Combines many features onto a single chip for simplified designs.
  • Superior I/O Standards: Ensures compatibility with the latest interface protocols.
  • Temperature Resilience: Operates effectively in challenging environmental conditions.
  • Advanced Signal Integrity: Maintains data integrity across high-speed transfers.

Applications

  • Advanced sensor networks
  • Critical control systems
  • Smart grid technologies
  • Intelligent transportation systems
  • Renewable energy solutions

The EP2S60F1020I4N provides developers with tools to craft highly efficient systems tailored for next-generation electronic applications.
