The TC4427COA713 is a robust, high-speed, dual-channel MOSFET driver manufactured by Microchip Technology, a leading provider of microcontroller and analog semiconductors. This device is specifically designed to convert low-power digital signals into high-current drive capable of directly driving large capacitive loads with high efficiency.

Key Features

• High Peak Output Current: The TC4427COA713 can deliver up to 1.5A of peak output current per channel, making it suitable for driving power MOSFETs and IGBTs.
• Wide Operating Range: It operates over a supply voltage range of 4.5V to 18V, accommodating various application needs.
• High-Speed Operation: With a propagation delay time of typically 30ns, this driver ensures high-speed operation, which is essential for fast-switching applications.
• Latch-Up Protected: It is resistant to latch-up up to 500mA of reverse current, providing reliable performance in harsh conditions.
• Low Shoot-Through Current: Designed with matched rise and fall times to minimize shoot-through current, enhancing the efficiency and reliability of the system.

Applications

The TC4427COA713 is ideal for a wide range of applications, including:

• Motor control circuits
• Switch Mode Power Supplies (SMPS)
• Power MOSFET gate drivers
• Pulse transformers drivers
• Line drivers

Package and Quality

The device comes in a 8-pin SOIC package, ensuring compactness and ease of integration into various designs. It is also available in the industrial temperature range, making it suitable for operation in challenging environmental conditions. Microchip Technology is committed to high standards of quality and reliability, and the TC4427COA713 is no exception, providing robust performance for critical applications.
