Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Reel - TR
Status Active
Driven Configuration Low-Side
Channel Type Independent
Number of Drivers 2
Gate Type N-Channel, P-Channel MOSFET
Supply Voltage - Operating 4.5 V to 18 V
Logic Voltage - VIL, VIH 0.8V, 2.4V
Current - Peak Output (Source, Sink) 4.5A, 4.5A
Input Type Non-Inverting
Rise and Fall Time 12ns, 12ns
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 1105913-TC4424AVOA713
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name TC4424A
Introduction Date June 08, 2006
ECCN EAR99
Country of Origin China, Taiwan, Thailand
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian TC4424AVOA713 CAD Model

Description

Microchip Technology TC4424AVOA713 MOSFET Driver

The TC4424AVOA713 is a robust, efficient, and versatile MOSFET driver from Microchip Technology, designed to cater to a wide range of power management applications. This high-speed, dual non-inverting driver is capable of delivering peak output currents of up to 3A, making it an ideal choice for driving large capacitive loads with rapid switching times. The device is part of the TC4424A series and comes in a compact 8-pin SOIC package, offering a space-saving solution for your circuit designs.

Engineered for precision and reliability, the TC4424AVOA713 operates over a wide supply voltage range of 4.5V to 18V. This flexibility ensures compatibility with various logic levels and provides the headroom needed for handling transient conditions. The driver's high current capability is matched by its high-speed performance, featuring rise and fall times of typically 30ns and 25ns, respectively, when driving a 1000pF load. This swift response makes it an excellent choice for high-frequency applications.

One of the notable features of the TC4424AVOA713 is its latch-up protection, which shields the device against up to 1.5A of reverse current, thereby enhancing its robustness against challenging conditions. Additionally, the driver incorporates built-in protection against over-temperature conditions, ensuring it operates within safe parameters and prolonging its lifespan.

The TC4424AVOA713 is also designed with matched rise and fall times, which minimizes the shoot-through current, thereby reducing power loss and improving overall efficiency. This characteristic is particularly beneficial in applications where power conservation is critical. Furthermore, the MOSFET driver's high peak output current and wide operating voltage range make it suitable for driving various loads, including capacitive, resistive, or inductive loads, in applications such as motor control, power supply modules, and switching power amplifiers.

Overall, the TC4424AVOA713 MOSFET driver from Microchip Technology stands out as a high-performance, reliable solution for designers looking to enhance the efficiency and responsiveness of their power management systems.
