Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel
Driven Configuration Low-Side
Channel Type Single
Number of Drivers 1
Gate Type N-Channel MOSFET
Supply Voltage (V) 3.5V ~ 14V
Logic Voltage - VIL, VIH 0.8V, 2.3V
Current - Peak Output (Source, Sink) 3A, 7A
Input Type Inverting, Non-Inverting
Rise / Fall Time 14ns, 12ns
Temperature Range - Operating -40°C ~ 125°C
Mounting Style SMD
Manufacturer Package 6-WDFN Exposed Pad
Supplier Device Package 6-WSON (3x3)
Family Part Number LM5112
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 1200417-LM5112SD
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LM5112SD CAD Model

Description

The LM5112SD from Texas Instruments is a versatile and high-performance gate driver designed to cater to a wide range of power management applications. This advanced device is capable of efficiently driving both the high-side and low-side N-Channel MOSFETs, making it an ideal choice for synchronous buck or half-bridge topologies, as well as full-bridge power converters.

Key Features

  • High Current Drive Capability: The LM5112SD offers robust output drive currents of up to 5A for the high-side and 5A for the low-side, ensuring rapid charging and discharging of the gate capacitance of large power MOSFETs for efficient switching.
  • Adaptive Dead-Time Control: To minimize cross-conduction and power loss, the device features adaptive dead-time control, which automatically adjusts the timing between the high-side and low-side drives.
  • Wide Supply Voltage Range: The device operates over a broad supply voltage range from 5V to 14V, providing flexibility in various system designs.
  • Independent Inputs: Separate inputs for high-side and low-side gates allow for independent control, offering designers the ability to optimize the drive for specific applications.
  • Under-Voltage Lockout (UVLO): Integrated UVLO protection for both the high-side and low-side drivers ensures that the MOSFETs are only operational when the gate drive voltage is sufficient, enhancing system reliability.

Applications

The LM5112SD is well-suited for use in a variety of applications that require high-efficiency power conversion. Common applications include:

  • DC-DC Converters
  • Motor Drives
  • Power Inverters
  • Class-D Audio Amplifiers
  • Power Supply Modules

Package and Reliability

The LM5112SD is offered in a compact, surface-mount WSON-10 package, which is optimized for thermal performance and space-saving on the PCB. Texas Instruments' commitment to quality ensures that this gate driver is manufactured to the highest standards, providing reliable and consistent performance in demanding environments.

For detailed specifications, application notes, and design resources, visit the Texas Instruments website to ensure your design takes full advantage of the LM5112SD's capabilities.
