Microchip Technology PIC16C54C-04/SO Microcontroller

The PIC16C54C-04/SO is a high-performance, CMOS, fully-static, 8-bit microcontroller fabricated by Microchip Technology. This particular model comes in a small-outline (SO) package, designed for surface-mount technology, making it an ideal choice for space-constrained applications. It operates at a speed of 4 MHz, providing a balanced compromise between power consumption and processing capability.

The device features a robust architecture with 512 words of EPROM program memory, making it suitable for applications where program updates are infrequent or not needed after the initial programming. The PIC16C54C-04/SO is equipped with 25 bytes of RAM data memory, which is ample for handling simple control tasks and data manipulation.

One of the key benefits of the PIC16C54C-04/SO microcontroller is its 12 I/O pins, which are highly flexible and can be configured for various interface requirements. This versatility makes it an excellent choice for a wide array of applications, including but not limited to, consumer electronics, automotive industries, and embedded systems.

The microcontroller also includes a built-in oscillator, which simplifies the design and reduces the number of external components needed. This feature, along with its power-saving sleep mode, makes the PIC16C54C-04/SO an energy-efficient option for battery-operated devices.

Other notable features of the PIC16C54C-04/SO include its wide operating voltage range of 2.5V to 5.5V, allowing it to function in various power environments. Additionally, it has an 8-level deep hardware stack and 33 single-word instructions, which contribute to its ease of use and programming flexibility.

Developers can take advantage of Microchip's extensive support network, including development tools, software libraries, and application notes, to streamline the product development process. Whether it's for simple control systems or more complex automation tasks, the PIC16C54C-04/SO from Microchip Technology offers a reliable and cost-effective solution for a multitude of embedded applications.
