Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Development Boards, Kits, Programmers - Evaluation Boards - Op Amps
Mfr MaxLinear Inc
Package Bulk
Product Status Obsolete
Channels per IC 2 - Dual
Amplifier Type Voltage Feedback
Output Type Rail-to-Rail
Slew Rate 145V/µs
-3db Bandwidth 260 MHz
Current - Output / Channel 55 mA
Current - Supply (Main IC) 4.2 mA
Voltage - Supply, Single/Dual (±) 2.5V ~ 5.5V, ±1.25V ~ 2.75V
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part CLC2005
Standard Package 1 pcs
MSL Level 1 (Unlimited)
ECCN OBSOLETE
Win Source Part Number 771557-CLC2005IMP8EVB
Ultra Librarian 3D Model Ultra Librarian CLC2005IMP8EVB CAD Model

Description

The CLC2005IMP8EVB is an evaluation board designed for testing and prototyping op amps from MaxLinear Inc.

  • Series: CLC2005
  • Package: Bulk
  • Output Type: Rail-to-rail
  • Bandwidth: 260 MHz
  • Application: Voltage feedback
  • Slew Rate: 145V/µs
  • Current Output per Channel: 55 mA
  • Voltage Supply: 2.5V to 5.5V (Single Supply), ±1.25V to ±2.75V (Dual Supply)
  • Quantity: 1 piece
  • Status: Obsolete
  • MSL Level: 1
