SS11V-07120-CH Kemet – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

SS11V-07120-CH

Part No SS11V-07120-CH
Manufacturer Kemet
Catalog Common Mode Chokes
Description CMC 12MH 700MA 2LN THROUGH HOLE
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Number of Lines 2
Inductance @ Frequency 12 mH @ 1 kHz
Current Rating (Max) 700mA
DC Resistance (DCR) (Max) 900mOhm
Voltage Rating - AC 250V
Temperature Range - Operating -25°C ~ 120°C
Mounting Type Through Hole
Size / Dimension 0.866" L x 0.571" W (22.00mm x 14.50mm)
Height (Max) 0.886" (22.50mm)
Case / Package Vertical, 4 PC Pin
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1530666-SS11V-07120-CH
Ultra Librarian 3D Model Ultra Librarian SS11V-07120-CH CAD Model

Description

N
