SNT-D30T Real Image
Same model may have multiple batches, images only for reference.

SNT-D30T

Part No SNT-D30T
Manufacturer Kemet
Catalog Common Mode Chokes
Datasheet
SNT-D30T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Filters>Common Mode Chokes
Mfr KEMET
Series SNT
Filter Type Signal Line
Number of Lines 2
Inductance @ Frequency 20 µH @ 100 kHz
Current Rating (Max) 500mA
DC Resistance (DCR) (Max) 98Ohm
Temperature Range - Operating -20°C ~ 60°C
Mounting Type Through Hole
Dimension 0.374" L x 0.236" W (9.50mm x 6.00mm)
Height (Max) 0.500" (12.70mm)
Package / Case Vertical, 2 PC Pin
Base Product Number SNT-D
Other Names UDLSNT0D30T000,399-SNT-D30TTR
Standard Package 1,000
MSL Level Not Applicable
ECCN EAR99
HTSUS 8548.00.0000
Win Source Part Number 1276805-SNT-D30T
Ultra Librarian 3D Model Ultra Librarian SNT-D30T CAD Model

Description

The SNT-D30T is a signal line common mode choke from the SNT series by KEMET.

  • Series: SNT series
  • Mounting Type: Through-Hole
  • Package/Case: 2 PC pin, Vertical
  • Current Rating (Max): 500mA
  • Inductance @ Frequency: 20μH @ 100kHz
  • DC Resistance (DCR): 98Ohm
  • Component: Common mode choke
  • Height: 12.70mm
  • Dimension: 9.50mm x 6.00mm
  • Temperature Range: -20°C to 60°C
  • Standard Package: 1000 units
  • REACH: unaffected
  • ECCN: EAR99
