Same model may have multiple batches, images only for reference.
SC-02-10GS Real Image
Same model may have multiple batches, images only for reference.

SC-02-10GS

Part No SC-02-10GS
Manufacturer Kemet
Catalog Common Mode Chokes
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Filters>Common Mode Chokes
Mfr KEMET
Series SC
Package Bulk
Filter Type Power Line
Number of Lines 2
Inductance @ Frequency 1 mH @ 100 kHz
Current Rating (Max) 2A
DC Resistance (DCR) (Max) 80mOhm
Voltage Rating - DC 250V
Voltage Rating - AC 250V
Temperature Range - Operating -25°C ~ 105°C
Mounting Type Through Hole
Dimension 0.591" Dia x 0.335" W (15.00mm x 8.50mm)
Height (Max) 0.591" (15.00mm)
Package / Case Vertical, No Base, 4 PC Pin
Base Product Number SC-02
Other Names 399-10645,UALSC0210GS000
Standard Package 1,000
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.31.4065
Win Source Part Number 1277089-SC-02-10GS
Ultra Librarian 3D Model Ultra Librarian SC-02-10GS CAD Model

Description

The KEMET common mode choke with Win Source Part Number 1277089-SC-02-10GS is a power line filter type component.

  • Voltage Rating: 250V AC
  • Current Rating: 2A
  • Height: 0.591 inches
  • Number of Lines: 2
  • Inductance: 1 mH @ 100 kHz
  • Mounting Type: Through Hole
  • Temperature Range: -25°C to 105°C
  • Series Name: SC
  • Standard Package: 1000
