Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer IXYS
Packaging Tube/Rail
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 1200V (1.2kV)
Current - Average Rectified (Io) 17A
Voltage - Forward (Vf) (Max) @ If 2.15V @ 12A
Speed(Frequency) Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 60ns
Current - Reverse Leakage @ Vr 750μA @ 1200V
Mounting Through Hole
Case / Package TO-220AC
Operating Temperature - Junction -40°C to 150°C
Win Source Part Number 040110-DSEI20-12A
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian DSEI20-12A CAD Model

Description

DSEI20-12A - Advanced High-Power Diode

The DSEI20-12A diode is a premium choice for high-power applications. It stands out in its class by offering superior recovery speed and efficiency, tailored for cutting-edge electronic projects.

Applications/Projects:

  • Renewable energy systems
  • Switching power supplies
  • High-efficiency rectification
  • Power management in automotive applications

Features and Benefits:

  • Rapid recovery time maximizes circuit efficiency.
  • High forward current rating for demanding applications.
  • Temperature-resistant design provides increased durability.
  • Space-saving TO-220AC package for flexible integration.

Additional Details: Ideal for engineers seeking durability and high performance, the DSEI20-12A is designed to give optimal results in challenging environments.
