Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr MDD
Series SOD-123
Package Tape & Reel
Product Status Active
Technology Standard
Voltage - DC Reverse (Vr) (Max) 250 V
Current - Average Rectified (Io) 250mA
Voltage - Forward (Vf) (Max) @ If 1.25 V @ 200 mA
Reverse Recovery Time (trr) 50 ns
Capacitance @ Vr, F 5pF @ 4V, 1MHz
Mounting Type Surface Mount
Package / Case SOD-123
Supplier Device Package SOD-123
Operating Temperature - Junction -55°C ~ 150°C
Base Product Number BAV21
Standard Package 12,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0070
Win Source Part Number 568995-BAV21W
Ultra Librarian 3D Model Ultra Librarian BAV21W CAD Model

Description

The BAV21W is a standard diode designed for rectification applications.

  • Maximum Reverse Voltage (Vr): 250V
  • Average Rectified Current (Io): 250mA
  • Forward Voltage (Vf): 1.25V @ 200mA
  • Reverse Recovery Time (trr): 50ns
  • Capacitance: 5pF @ 4V and 1MHz
  • Package: SOD-123
  • Temperature Range: -55°C to 150°C
