Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Integrated Circuits(ICs)
Family Embedded - Microcontrollers
Manufacturer Intel
Series 80C
Packaging Tube
Core Processor MCS 96
Core Size 16-Bit
Speed 16MHz
Connectivity SIO
Peripherals PWM, WDT
Number of I/O 48
Program Memory Type ROMless
RAM Size 232 x 8
Operating Supply Voltage 4.5 V ~ 5.5 V
Data Converters A/D 8x10b
Oscillator Type External
Operating Temperature Range 0°C ~ 70°C (TA)
Package 68-LCC (J-Lead)
Manufacturer Device Package 68-PLCC
Win Source Part Number 141226-N80C196KB16
Family Name 80C196
Introduction Date July 01, 1994
ECCN EAR99
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian N80C196KB16 CAD Model

Description

The Intel 141226-N80C196KB16 microcontroller is a high-quality electronic component that is commonly used in various applications.

  • Speed: 16MHz
  • Series: 80C
  • Package: Tube
  • Core Processor: MCS 96
  • Core Size: 16-bit
  • Package: 68-LCC (J-Lead)
  • Manufacturer Device Package: 68-PLCC
  • Connectivity: SIO
  • Peripherals: PWM, WDT
  • I/O: 48
  • RAM Size: 232 x 8
  • Data Converter: A/D 8x10b
  • Oscillator Type: External
