M20-9733645

Name: M20-9733645
Brand: Harwin Inc.
SKU: 1352287
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	M20-9733645
Manufacturer	Harwin Inc.
Catalog	Rectangular Connectors
Description	CONN HEADER VERT 36POS 2.54MM / Connector Header Through Hole 36 position 0.100" (2.54mm)
Datasheet	M20-9733645 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Connectors, Interconnects - Rectangular Connectors - Headers, Male Pins
Mfr	Harwin Inc.
Series	M20
Package	Bulk
Connector Type	Header, Cuttable
Contact Type	Male Pin
Pitch - Mating	0.100" (2.54mm)
Number of Positions	36
Number of Rows	1
Number of Positions Loaded	All
Style	Board to Board or Cable
Shrouding	Unshrouded
Mounting Type	Through Hole
Termination	Solder
Fastening Type	Push-Pull
Contact Length - Mating	0.276" (7.00mm)
Contact Length - Post	0.122" (3.10mm)
Overall Contact Length	0.496" (12.60mm)
Insulation Height	0.100" (2.54mm)
Contact Shape	Square
Contact Finish - Mating	Gold
Contact Material	Brass
Insulation Material	Polyamide (PA6T) , Nylon 6T
Temperature Range - Operating	-40°C ~ 105°C
Material Flammability Rating	UL94 V-0
Insulation Color	Black
Current Rating (Amps)	3A per Contact
Mated Stacking Heights	10.04mm, 10.64mm, 11.04mm, 16.54mm
Base Product Number	M20-973
Standard Package	200
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8536.69.4040
Win Source Part Number	1352287-M20-9733645
Ultra Librarian 3D Model	Ultra Librarian M20-9733645 CAD Model

Description

The M20 series header connector is a male pin type connector with a cuttable design, suitable for through-hole mounting on printed circuit boards or cable applications.

Connector Type: Header, Male Pins
Style: Cuttable
Pitch: 0.100" (2.54mm)
Contact Shape: Square
Current Rating (Per Contact): 3A
Operating Temperature: -40°C ~ 105°C
Number of Positions Loaded: All
Number of Positions: 36
Number of Rows: 1
Contact Material: Brass
Contact Finish - Mating: Gold
Packaging: Bulk
Material Flammability Rating: UL94 V-0
Mated Stacking Heights: 10.04mm, 10.64mm, 11.04mm, 16.54mm
Mounting Type: Through Hole
