MOC3083M Real Image MOC3083M real image3544
Same model may have multiple batches, images only for reference.
MOC3083M Real Image MOC3083M real image3544
MOC3083M Real Image MOC3083M real image3544
Same model may have multiple batches, images only for reference.

MOC3083M

Part No MOC3083M
Manufacturer Fairchild/ON Semiconductor
Catalog Optoisolators - Triac, SCR Output
Description Triac AC-OUT 1-CH 800V 6-Pin PDIP W Tube / OPTOISOLATOR 4.17KV TRIAC 6DIP
Datasheet
MOC3083M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Active
Output Type Triac
Zero Crossing Circuit Yes
Number of Channels 1
Isolation Voltage 4170Vrms
Voltage - Off State 800V
Static dV/dt (Min) 600V/μs
Current - LED Trigger (Ift) (Max) 5mA
Current - Hold (Ih) 500μA (Typ)
Forward Voltage 1.3V
Continuous forward current- Max 60mA
Temperature Range - Operating -40°C to 85°C
Mounting Through Hole
Case / Package 6-DIP
Approvals UL
Win Source Part Number 024197-MOC3083M
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Quantity per package 1k pcs
Family Name MOC3083M
Introduction Date April 14, 2003
ECCN EAR99
Country of Origin Republic of Korea, Thailand
Halogen Free Not Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian MOC3083M CAD Model

Description

The MOC3083M is a triac output optocoupler that consists of an LED optically coupled to a zero-crossing triac.

  • Description: It is designed for interfacing with low voltage control systems.
  • Voltage Off-State: 800V
  • Isolation Voltage: 4170Vrms
  • Continuous Forward Current: 60mA
  • LED Trigger Current (Max): 5mA
  • Package Type: 6-DIP
  • Operating Temperature: -40°C to 85°C
  • Approvals: UL
  • Supply and Demand Status: sufficient
  • Common Applications: isolators
