Diodes Incorporated PI3EQX12902BZLEX Product Overview

The PI3EQX12902BZLEX is a high-performance, PCIe 3.0 signal ReDriver from Diodes Incorporated designed to enhance signal quality by performing receive equalization on deteriorated input signal followed by transmit de-emphasis, maximizing system performance. It is ideal for applications that demand high-speed data transmissions, such as server, storage, data center, and high-performance computing environments.

Key Features

• PCIe 3.0 Compliance: This ReDriver supports 8.0 GT/s data rates of PCIe 3.0 specification, ensuring compatibility with the latest high-speed interfaces.
• Signal Conditioning: The device provides programmable equalization, swing, and flat gain to optimize performance over a variety of physical mediums by reducing inter-symbol interference.
• Low Power Consumption: PI3EQX12902BZLEX is designed for power efficiency, which is critical in high-speed, high-density computing applications.
• Transparent Operation: It operates in a manner transparent to its host without requiring driver or software additions.
• Flexibility: The device offers adjustable settings for various system requirements and can be used in multiple platforms, enhancing its versatility.

Applications

• High-performance workstations and desktops
• Data center and enterprise storage systems
• Server and networking equipment
• Embedded systems and industrial PCs

Technical Specifications

The PI3EQX12902BZLEX is available in a 42-contact TQFN package and is specified for operation from -40°C to 85°C. It integrates both AC coupling capacitors and a termination resistor to reduce external component count and simplify PCB layout.

Ordering Information

For ordering the PI3EQX12902BZLEX, or to request samples and technical documentation, please visit the Diodes Incorporated website or contact their sales representatives. Ensure that you are getting genuine products by purchasing directly from Diodes Incorporated or through their authorized distribution channels.
