Products specifications Report Issue?

Category Switches - Toggle Switches
Mfr C&K Components
Series ET
Package Tape & Reel
Product Status Active
Mounting Type Surface Mount, Right Angle
Circuit SPDT
Switch Function On-On
Current Rating (Amps) 0.4VA (AC/DC)
Voltage Rating - AC 20 V
Voltage Rating - DC 20 V
Actuator Type Standard Round
Actuator Length 6.10mm
Illumination Non-Illuminated
Termination Style Gull Wing
Bushing Thread Unthreaded
Ingress Protection IP57 - Dust Protected, Waterproof
Features Epoxy Sealed Terminals
Temperature Range - Operating -30°C ~ 85°C
Actuator Material Brass, Chrome Plated
Electrical Life 60,000 Cycles
Base Product Number ET01MD
Standard Package 600 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8536.50.9065
Win Source Part Number 590086-ET01MD1SAPE
Ultra Librarian 3D Model Ultra Librarian ET01MD1SAPE CAD Model

Description

The ET01MD1SAPE is a toggle switch from the ET series manufactured by C&K Components. C&K Components manufactures it.

  • Termination Style: Gull Wing
  • Feature: Epoxy Sealed Terminals, Dust Protected, Waterproof (IP57)
  • Actuator Material: Brass and Chrome Plated
  • Voltage Rating (AC/DC): 20V
  • Switch Function: SPDT, On-On
  • Actuator Type: Standard Round, Length 6.10mm
  • Electrical Life: 60,000 Cycles
  • Illumination: Non-Illuminated
  • Mounting: Surface Mount, Right Angle
  • Operating Temperature: -30°C to 85°C
  • MSL Level: 3 (168 Hours)
  • REACH: Affected
  • HTSUS Code: 8536.50.9065
  • Base Product Number: ET01MD
