HCPL-2232-000E Real Image HCPL-2232-000E real image4562 HCPL-2232-000E real image4563
Same model may have multiple batches, images only for reference.
HCPL-2232-000E Real Image HCPL-2232-000E real image4562 HCPL-2232-000E real image4563
HCPL-2232-000E Real Image HCPL-2232-000E real image4562 HCPL-2232-000E real image4563
Same model may have multiple batches, images only for reference.

HCPL-2232-000E

Part No HCPL-2232-000E
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description Optocoupler Logic-Out Totem-Pole DC-IN 2-CH 8-Pin PDIP Tube / OPTOISO 3.75KV 2CH PSH PULL 8DIP
Datasheet
HCPL-2232-000E Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube/Rail
Status Active
Number of Channels 2
Inputs - Side 1/Side 2 2/0
Isolation Voltage 3750Vrms
Common Mode Transient Immunity (Min) 10kV/μs
Input Type DC
Output Type Push-Pull, Totem Pole
Channel Output Current 25mA
Data Rate 5MBd
Propagation Delay tpLH / tpHL (Max) 300ns, 300ns
Rise and Fall Time 30ns, 7ns
Forward Voltage 1.5V
Continuous forward current- Max 10mA
Supply Voltage - Operating 4.5 V to 20 V
Temperature Range - Operating -40°C to 85°C
Mounting Through Hole
Case / Package 8-DIP
Win Source Part Number 016858-HCPL-2232-000E
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 50
Family Name HCPL-2232
Introduction Date May 31, 2005
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian HCPL-2232-000E CAD Model

Description

The Broadcom Limited 016858-HCPL-2232-000E is an optocoupler with a push-pull and totem pole output type.

  • Output Type: Push-Pull, Totem Pole
  • Data Rate: 5MBd
  • Forward Voltage: 1.5V
  • Common Mode Transient Immunity: 10kV/μs
  • Propagation Delay (Max) tpLH/tpHL: 300ns / 300ns
  • Isolation Voltage: 3750Vrms
  • Product Category: Isolators
  • Operating Temperature: -40°C to 85°C
  • Package: 8-DIP
  • Supply Voltage: 4.5V to 20V
  • Rise and Fall Time: 30ns / 7ns
  • Channel Output Current: 25mA
  • Continuous Forward Current: 10mA
  • Supply and Demand: Balanced
  • Quantity per Package: 50
