Same model may have multiple batches, images only for reference.
SRF1006-202Y Real Image
Same model may have multiple batches, images only for reference.

SRF1006-202Y

Part No SRF1006-202Y
Manufacturer Bourns Inc.
Catalog Common Mode Chokes
Datasheet
SRF1006-202Y Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Filters>Common Mode Chokes
Mfr Bourns Inc.
Series SRF1006
Package Tape & Reel (TR)
Filter Type Signal Line
Number of Lines 2
Impedance @ Frequency 2 kOhms @ 500 kHz
Inductance @ Frequency 2 mH @ 100 kHz
Current Rating (Max) 400mA
DC Resistance (DCR) (Max) 270mOhm
Voltage Rating - DC 50V
Temperature Range - Operating -40°C ~ 105°C
Mounting SMD (SMT)
Dimension 0.394" L x 0.343" W (10.00mm x 8.70mm)
Height (Max) 0.256" (6.50mm)
Package / Case Horizontal, 4 PC Pad
Base Product Number SRF1006
Standard Package 800
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1277154-SRF1006-202Y
Ultra Librarian 3D Model Ultra Librarian SRF1006-202Y CAD Model

Description

The SRF1006-202Y is a common mode choke from Bourns Inc.

  • Series: SRF1006 series
  • Filter Application: Signal line filters
  • Package: Tape and reel
  • Voltage Rating: 50V DC
  • Current Rating (Max): 400mA
  • Standard Package: 800
  • Mounting Type: Surface mount device
  • Package/Case: Horizontal, 4 PC pad
  • Height: 0.256 inches
  • Dimension: 0.394 inches in length and 0.343 inches in width
  • Impedance @ Frequency: 2 kOhms @ 500 kHz
  • Inductance @ Frequency: 2 mH @ 100 kHz
  • DC Resistance (DCR): 270mOhm
  • Temperature Range - Operating: -40°C to 105°C
