SRF0602-820Y Real Image
Same model may have multiple batches, images only for reference.

SRF0602-820Y

Part No SRF0602-820Y
Manufacturer Bourns Inc.
Catalog Common Mode Chokes
Datasheet
SRF0602-820Y Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Filters>Common Mode Chokes
Mfr Bourns Inc.
Series SRF0602
Package Tape & Reel
Filter Type Signal Line
Number of Lines 2
Impedance @ Frequency 220 Ohms @ 3 MHz
Inductance @ Frequency 82 µH @ 10 kHz
Current Rating (Max) 300mA
DC Resistance (DCR) (Max) 20mOhm
Voltage Rating - DC 50V
Temperature Range - Operating -40°C ~ 105°C
Mounting SMD (SMT)
Dimension 0.256" L x 0.142" W (6.50mm x 3.60mm)
Height (Max) 0.071" (1.80mm)
Package / Case Horizontal, 4 PC Pad
Base Product Number SRF0602
Other Names SRF0602-820Y,SRF0602-820YCT,118-SRF0602-820YCT,-SRF0602-820YCT,118-SRF0602-820YDKR,SRF0602-820YTR,SRF0602-820YCT,-SRF0602-820Y,-SRF0602-820Y,118-SRF0602-820YTR,SRF0602820Y,SRF0602-820YTR,-SRF0602-820YTR
Standard Package 1,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1277167-SRF0602-820Y
Ultra Librarian 3D Model Ultra Librarian SRF0602-820Y CAD Model

Description

The Bourns 1277167-SRF0602-820Y is a common mode choke filter that is designed to suppress EMI/RFI noise.

  • Series: SRF0602 series
  • Filter Type: Signal line type filter
  • Package Type: Tape and reel
  • DC Resistance (DCR): 20mOhm (Maximum)
  • Impedance @ Frequency: 220 Ohms @ a frequency of 3 MHz
  • Inductance @ Frequency: 82 µH @ a frequency of 10 kHz
  • Current Rating: 300mA
  • Voltage Rating: 50V DC
  • Operating Temperature Range: -40°C to 105°C
  • Package/Case: Horizontal and has 4 PC pads
  • Height: 0.071" (1.80mm)
  • Dimension: 0.256" L x 0.142" W (6.50mm x 3.60mm)
  • MSL Level: 1 (Unlimited)
  • REACH Status: REACH unaffected
  • Application: Used in a variety of applications, including automotive, industrial, and telecommunications.
