Same model may have multiple batches, images only for reference.
7416-RC Bourns Inc. – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

7416-RC

Part No 7416-RC
Manufacturer Bourns Inc.
Catalog Common Mode Chokes
Description CMC 30MH 500MA 2LN TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Filter Type Power Line
Number of Lines 2
Inductance @ Frequency 30 mH @ 1 kHz
Current Rating (Max) 500mA
DC Resistance (DCR) (Max) 1.73Ohm
Voltage Rating - AC 250V
Temperature Range - Operating -55°C ~ 105°C
Mounting Type Through Hole
Size / Dimension 0.748" L x 0.669" W (19.00mm x 17.00mm)
Height (Max) 0.827" (21.00mm)
Case / Package Vertical, 4 PC Pin
Package Bulk
Supply and Demand Status Limited
Win Source Part Number 1530320-7416-RC
Ultra Librarian 3D Model Ultra Librarian 7416-RC CAD Model
