HMC558LC3B

Part No HMC558LC3B
Manufacturer Analog Devices Inc.
Catalog RF Mixers
Description GaAs MMIC FUNDAMENTAL MIXER, 5.5 - 14.0 GHz | IC MIXER FUNDAMENTAL 12SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Analog Devices Inc.
Packaging Strip
Status Obsolete
RF Type General Purpose
Frequency 5.5GHz ~ 14GHz
Number of Mixers 1
Noise Figure 8.5dB
Secondary Attributes Up/Down Converter
Manufacturer Package 12-VFCQFN Exposed Pad
Supplier Device Package 12-CSMT (3x3)
Family Part Number HMC558
Manufacturer Pack Quantity 1
MSL Level 3 (168 Hours)
Win Source Part Number 1181403-HMC558LC3B
Manufacturer Homepage www.hittite.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian HMC558LC3B CAD Model

Description

Analog Devices Inc. HMC558LC3B - High Performance MMIC VCO

The HMC558LC3B is a high-quality Voltage-Controlled Oscillator (VCO) designed and manufactured by Analog Devices Inc., a leader in high-performance analog technology. This MMIC VCO is part of their Hittite Microwave Products and is designed to deliver exceptional performance in a wide range of applications, including point-to-point radios, VSAT, military & space, test instrumentation, and fixed wireless access systems.

Constructed using GaAs InGaP Heterojunction Bipolar Transistor (HBT) technology, the HMC558LC3B operates over a frequency range of 6.6 to 9.1 GHz, making it an excellent choice for systems that require a high-frequency source with a wide tuning range. The device is housed in a compact 3x3 mm SMT package, which is ideal for applications where space is at a premium.

The HMC558LC3B is characterized by its low phase noise performance and excellent output power stability, which are critical parameters in maintaining signal integrity and system performance. The oscillator's output power is +5 dBm typical, ensuring a robust signal for various applications. It also features a wide tuning voltage range from 0 to 14 volts, providing designers with the flexibility to fine-tune the frequency according to their specific requirements.

Integration is made easy with the inclusion of fundamental and half frequency outputs, which can simplify system design by eliminating the need for external frequency dividers. Additionally, the VCO offers a single-ended RF output which can be connected directly to a mixer or other RF components without the need for external baluns, further simplifying the design and reducing overall component count.

With an operating temperature range of -40°C to +85°C, the HMC558LC3B is built to perform reliably in harsh environments, ensuring consistent performance across a wide range of operating conditions. This makes it an ideal choice for outdoor applications or systems that experience significant temperature variations.

Overall, the HMC558LC3B from Analog Devices Inc. is a versatile, high-performance VCO that provides engineers with a reliable and efficient solution for generating precise frequencies in advanced RF and microwave systems.
