EVAL-AD7738EBZ

Part No EVAL-AD7738EBZ
Manufacturer Analog Devices Inc.
Catalog Evaluation Boards - Analog to Digital Converters (ADCs)
Description BOARD EVAL FOR AD7738 / AD7738 ADC Evaluation Board
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Development Boards, Kits, Programmers
Manufacturer Analog Devices Inc.
Number of Converters 1
Resolution 24
Sampling Rate 15.4k
Data Interface Serial
Input Range ±2.5 V
Power (Typ) @ Conditions 85mW @ 5 V
Utilized IC / Part AD7738
Supplied Contents Board(s)
Win Source Part Number 772365-EVAL-AD7738EBZ
Popularity Medium
Supply and Demand Status Limited
Family Name EVAL-AD7738EB
Introduction Date July 23, 2002
ECCN EAR99
Country of Origin Ireland
Estimated EOL Date 2029
Ultra Librarian 3D Model Ultra Librarian EVAL-AD7738EBZ CAD Model

Description

The EVAL-AD7738EBZ is a high-performance evaluation board offered by Analog Devices Inc., designed to assess the capabilities of the AD7738, a 24-bit, high precision, Sigma-Delta (ΣΔ) analog-to-digital converter (ADC). This evaluation board provides an efficient and user-friendly platform for testing the full features of the AD7738 ADC in various applications.

Key Features

  • 24-bit ΣΔ ADC with eight differential input channels
  • Exceptional noise performance with a programmable gain amplifier (PGA)
  • Flexible I/O voltage ranges to interface with a variety of logic levels
  • On-board reference and reference buffer
  • Easy-to-use evaluation software for data analysis and register configuration
  • USB interface for quick connectivity with PCs

Applications

The EVAL-AD7738EBZ is suitable for a wide range of precision measurement applications, including:

  • Industrial process control
  • Instrumentation and control systems
  • Data acquisition systems
  • Medical and scientific research equipment

Design and Functionality

The board is designed to highlight the AD7738's eight differential analog input channels, which can be configured for various sensor types. With its integrated PGA, the EVAL-AD7738EBZ allows for a wide variety of input signals, ensuring precise measurements across diverse ranges. The ADC features a high level of integration, reducing the need for external components and simplifying the design process for engineers.

Powered through the USB connection, the EVAL-AD7738EBZ is accompanied by dedicated evaluation software that facilitates data capture, display, and analysis, as well as device configuration. This software is a critical tool for designers looking to fine-tune the performance of the AD7738 for their specific applications.

For developers and engineers seeking to rapidly prototype and test their designs, the EVAL-AD7738EBZ from Analog Devices Inc. represents a robust solution, offering the precision and flexibility needed to meet the demands of high-accuracy measurement systems.
