ADXL377BCPZ-RL7 - High-G Accelerometer from Analog Devices Inc.

The ADXL377BCPZ-RL7 is a robust, high-performance analog accelerometer from the esteemed manufacturer, Analog Devices Inc. This sensor is specifically designed to measure acceleration with a full-scale range of ±200g. It is capable of detecting both dynamic acceleration (e.g., vibration) and static acceleration (e.g., gravity).

Encased in a compact LFCSP (Lead Frame Chip Scale Package), the ADXL377BCPZ-RL7 offers a small footprint of 4mm x 4mm, making it an ideal choice for space-constrained applications. Its low power consumption and single analog voltage output make it simple to integrate into existing systems, while its high-g range makes it suitable for a wide array of applications, including shock detection, impact monitoring, and sports equipment analysis.

The device operates on a supply voltage ranging from 2.0V to 3.6V, which allows for flexibility in battery-powered applications. It also features a bandwidth that can be selected by the user, providing a customizable approach to signal processing. The ADXL377BCPZ-RL7 is temperature-stable and calibrated to ensure accurate measurements over its entire operating temperature range of -40°C to +85°C.

Integration is straightforward due to its analog output, which can be directly connected to an ADC (Analog-to-Digital Converter) for digital processing. The sensor's high-g capabilities make it particularly useful in areas such as automotive crash testing, concussion detection in helmets, and other applications where extreme forces may be encountered.

Analog Devices Inc. has a reputation for producing high-quality, reliable components, and the ADXL377BCPZ-RL7 is no exception. With its robust design, high precision, and versatility, this accelerometer is a top choice for engineers and designers looking to measure high levels of acceleration with confidence.

Key Features:

• Measurement Range: ±200g
• Compact LFCSP Package: 4mm x 4mm
• Low Power Consumption
• Flexible Supply Voltage: 2.0V to 3.6V
• User-Selectable Bandwidth
• Temperature Stable and Calibrated
• Wide Operating Temperature Range: -40°C to +85°C
