AD7797BRUZ-REEL

Part No AD7797BRUZ-REEL
Manufacturer Analog Devices Inc.
Catalog Data Acquisition - Analog to Digital Converters (ADC)
Description Low Power, 16-/24-Bit Sigma-Delta ADC for Bridge Sensors | IC ADC 24BIT SIGMA-DELTA 16TSSOP
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Analog Devices Inc.
Packaging Tape and Reel
Resolution 24
Sampling Rate (Per Second) 123
Number of Inputs 1
Input Type Differential
Data Interface SPI, DSP
Configuration MUX-ADC
Number of A/D Converters 1
Architecture Sigma-Delta
Reference Type External
Supply Voltage , Analog 2.7V ~ 5.25V
Supply Voltage , Digital 2.7V ~ 5.25V
Features Temperature Sensor
Temperature Range - Operating -40°C ~ 85°C
Manufacturer Package 16-TSSOP
Supplier Device Package 16-TSSOP
Mounting Style SMD
Family Part Number AD7797
Manufacturer Pack Quantity 2,500
MSL Level 1 (Unlimited)
Win Source Part Number 1137672-AD7797BRUZ-REEL
Manufacturer Homepage www.analog.com
Family Name AD7797
Introduction Date April 01, 2006
ECCN EAR99
Country of Origin Taiwan
Halogen Free Not Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian AD7797BRUZ-REEL CAD Model

Description

The AD7797BRUZ-REEL is a high-precision, low-power, 24-bit sigma-delta (σδ) analog-to-digital converter (ADC) offered by Analog Devices Inc., a leader in high-performance semiconductors. This ADC is specifically designed for low-frequency measurement applications that require a high degree of accuracy and noise rejection.

Featuring a complete analog front-end for fully differential input signals, the AD7797BRUZ-REEL is well-suited for applications such as process control, smart transmitters, industrial instrumentation, and portable instrumentation. Its precision performance is complemented by its low power consumption, making it ideal for battery-powered devices and remote sensors.

Key Features:

  • Resolution: 24-bit σδ ADC with a very low noise floor, providing high-resolution measurements.
  • Input Type: Fully differential input channels that enhance common-mode noise rejection and improve signal integrity.
  • Data Interface: Serial interface compatible with SPI, QSPI™, MICROWIRE™, and DSP interface standards, ensuring easy integration with most microcontrollers and digital systems.
  • Power Supply: Single-supply operation with a wide range of 2.7 V to 5.25 V, accommodating various system power requirements.
  • Low Power: Low current consumption of 1 mA max in normal operation and a power-down mode that reduces the current to 1 µA max, optimizing battery life for portable applications.
  • On-Chip Features: Includes an on-chip oscillator, reference buffer, temperature sensor, and programmable gain amplifier (PGA), simplifying system design and reducing external component count.
  • Packaging: Supplied in a compact TSSOP (thin shrink small outline package) that is suitable for space-constrained applications.
  • Temperature Range: Specified performance from -40°C to +85°C, ensuring reliable operation in a wide range of environmental conditions.

With its robust feature set, the AD7797BRUZ-REEL from Analog Devices Inc. addresses the needs of precision data acquisition systems by delivering high-accuracy measurements in a compact and power-efficient package. This ADC is an excellent choice for designers looking to achieve the best performance in their sensor interface applications.
