Same model may have multiple batches, images only for reference.
7448225007 Wurth Electronics Inc – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

7448225007

Part No 7448225007
Manufacturer Wurth Electronics Inc
Catalog Common Mode Chokes
Description CMC 700UH 5A 2LN TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Filter Type Power Line
Number of Lines 2
Inductance @ Frequency 700 µH @ 100 kHz
Current Rating (Max) 5A
DC Resistance (DCR) (Max) 15mOhm
Voltage Rating - AC 250V
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Through Hole
Size / Dimension 0.728" L x 0.571" W (18.50mm x 14.50mm)
Height (Max) 0.866" (22.00mm)
Case / Package Vertical, 4 PC Pin
Package Tray
Supply and Demand Status Shortage
Win Source Part Number 1507188-7448225007
Ultra Librarian 3D Model Ultra Librarian 7448225007 CAD Model
