7448021230

Part No 7448021230
Manufacturer Wurth Electronics Inc
Catalog Common Mode Chokes
Description CMC 30MH 1.2A 2LN TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Filter Type Power Line
Number of Lines 2
Inductance @ Frequency 30 mH @ 10 kHz
Current Rating (Max) 1.2A
DC Resistance (DCR) (Max) 280mOhm
Voltage Rating - AC 250V
Temperature Range - Operating -40°C ~ 125°C
Features Nanocrystalline Core
Mounting Type Through Hole
Size / Dimension 0.709" L x 0.551" W (18.00mm x 14.00mm)
Height (Max) 0.866" (22.00mm)
Case / Package Vertical, 4 PC Pin
Package Tray
Supply and Demand Status Shortage
Win Source Part Number 1507077-7448021230
Ultra Librarian 3D Model Ultra Librarian 7448021230 CAD Model
