VS-60CTQ150-M3 VS-60CTQ150-M3 real image16842
Same model may have multiple batches, images only for reference.
VS-60CTQ150-M3 VS-60CTQ150-M3 real image16842
VS-60CTQ150-M3 VS-60CTQ150-M3 real image16842
Same model may have multiple batches, images only for reference.

VS-60CTQ150-M3

Part No VS-60CTQ150-M3
Manufacturer Vishay
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY SCHOTTKY 150V TO220
Datasheet
VS-60CTQ150-M3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Diode Arrays
Mfr Vishay
Package Tube
Product Status Active
Diode Configuration 1 Pair Common Cathode
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 150 V
Current - Average Rectified (Io) (per Diode) 30A
Voltage - Forward (Vf) (Max) @ If 1.09 V @ 60 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 75 µA @ 150 V
Operating Temperature - Junction -55°C ~ 175°C
Mounting Type Through Hole
Package / Case TO-220-3
Supplier Device Package TO-220-3
Base Product Number 60CTQ150
Standard Package 50 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 852230-VS-60CTQ150-M3
Ultra Librarian 3D Model Ultra Librarian VS-60CTQ150-M3 CAD Model

Description

The 852230-VS-60CTQ150-M3 is a fast recovery Schottky diode array designed for rectification applications.

  • Voltage Rating: 150V
  • Forward Voltage Drop: 1.09V @ forward current of 60A
  • Current Rating: 30A
  • Reverse Leakage Current: 75μA @ maximum reverse voltage
  • Operating Temperature: -55°C to 175°C
  • Package Type: TO-220-3
  • Mounting Type: Through-hole
