VS-20TQ045PBF Vishay
Same model may have multiple batches, images only for reference.

VS-20TQ045PBF

Part No VS-20TQ045PBF
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description Schottky Rectifier, 20 A
Datasheet
VS-20TQ045PBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay Semiconductor Diodes Division
Packaging Tube
Diode Type Schottky
Voltage - DC Reverse (Vr) (Maximum) 45V
Current - Average Rectified (Io) 20A
Voltage - Forward (Vf) (Maximum) @ If 570mV @ 20A
Speed Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 2.7mA @ 45V
Capacitance @ Vr, F 1400pF @ 5V, 1MHz
Mounting Style Through Hole
Package TO-220-2
Manufacturer Package TO-220AC
Operating Temperature - Junction -55°C ~ 150°C
Win Source Part Number 1279806-VS-20TQ045PBF
Manufacturer Homepage www.vishay.com
Popularity Medium
Supply and Demand Status Balance
Quantity per package 50
Ultra Librarian 3D Model Ultra Librarian VS-20TQ045PBF CAD Model

Description

The Vishay 1279806-VS-20TQ045PBF is a Schottky diode designed for fast recovery applications.

  • Current Average Rectified: 20A
  • Voltage Forward (Vf): 570mV (maximum) @ 20A
  • Voltage DC Reverse (Vr): 45V
  • Current Reverse Leakage @ Vr: 2.7mA @ 45V
  • Capacitance @ Vr, F: 1400pF @ 5V, 1MHz
  • Package: TO-220-2
  • Manufacturer Package: TO-220AC
  • Operating Temperature Range: -55°C to 150°C
  • Family: Discrete semiconductor products
  • Packaging: Tube
  • Quantity per Package: 50
  • Supply and demand: Balanced
  • Alternative Parts: MS1650, 12TQ040, and 18TQ040
