Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Current Transmitter
Input Type Voltage
Output Type Voltage
Operating Supply Current 20mA
Temperature Range - Operating -55°C to 125°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 036672-XTR115UA
Family Name XTR115
Introduction Date June 01, 2005
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Signal Processing, Industrial, Automation & Process Control, Test & Measurement
Ultra Librarian 3D Model Ultra Librarian XTR115UA CAD Model

Description

Introducing the XTR115UA from Texas Instruments

The XTR115UA is a precision current output converter designed to transmit analog 4-20mA signals over an industry-standard current loop. This robust component from Texas Instruments is an essential building block in industrial control systems where long-distance signal integrity is paramount. The XTR115UA is specifically engineered to provide reliable performance in harsh environments, making it an ideal choice for process control applications.

Key Features of the XTR115UA

  • Current Loop Driver: The XTR115UA can drive a 4-20mA current loop, providing a standardized output that can be easily interpreted by monitoring equipment.
  • Low Span Error: With a low span error of ±0.1% at 25°C, the device ensures accurate signal transmission and minimal deviation over time, which is critical for precise control systems.
  • Wide Supply Range: The device operates over a wide supply voltage range from 7.5V to 36V, offering flexibility in various power environments and making it suitable for many different types of industrial equipment.
  • High Output Impedance: The high output impedance of the current loop driver ensures stable operation over the entire range of the loop current without being affected by changes in the load.
  • External Trim Adjustments: It includes provisions for external trimming, which allows for fine-tuning of the output current for calibration purposes, ensuring that the system can maintain its precision over time.
  • Robust Package: The XTR115UA comes in a durable 8-pin SOIC package, which provides a compact footprint while maintaining the robustness required for industrial applications.

Applications of the XTR115UA

With its reliable performance and flexible features, the XTR115UA is well-suited for a variety of applications, including:

  • Process control and automation
  • Factory automation systems
  • PLC interface
  • Remote data acquisition
  • Industrial control loops

In summary, the Texas Instruments XTR115UA is a versatile and precise current loop driver that offers the reliability and performance needed for critical industrial and automation tasks. Its ability to maintain signal integrity over long distances and in challenging environments makes it a go-to component for engineers and designers looking to create robust control systems.
