The USBN9604SLBX/NOPB is a versatile USB node controller integrated circuit designed by Texas Instruments, tailored for USB full-speed peripheral applications. This robust device is compliant with the USB Specification 1.1 and is optimized to manage USB data transfers while minimizing the workload on the host processor. The USBN9604SLBX/NOPB is an ideal solution for developers looking to integrate USB connectivity into their designs with minimal design complexity and cost.

Key Features

• USB Compliance: Fully complies with USB Specification 1.1 for full-speed (12 Mbps) peripherals.
• Interface: Offers an 8-bit parallel interface, facilitating easy connection to microcontrollers or processors.
• Endpoint Support: Features 14 programmable endpoints with flexible endpoint size configurations, enhancing data management capabilities.
• Integrated SIE: Contains a Serial Interface Engine (SIE) that handles low-level USB protocol details, streamlining development.
• Integrated FIFO: Equipped with a built-in FIFO memory for endpoint buffering, ensuring efficient data handling.
• Power Management: Supports suspend/resume detection logic for power conservation, making it suitable for battery-powered applications.
• Packaging: Available in a compact 32-pin LQFP package, saving board space and easing integration into various designs.

Applications

The USBN9604SLBX/NOPB is designed for a wide range of applications that require USB connectivity. It is particularly suitable for use in devices such as keyboards, mice, joysticks, and other human interface devices (HIDs), as well as in more complex peripherals like printers, scanners, and cameras. Its ease of integration and comprehensive feature set make it an excellent choice for enhancing existing products or developing new innovative solutions with USB capabilities.

Quality and Reliability

Texas Instruments is known for its commitment to quality, and the USBN9604SLBX/NOPB is no exception. It is manufactured to meet high standards of performance and reliability, ensuring that it can withstand the demands of real-world applications. The NOPB designation indicates that this device is provided in a lead-free package, reflecting TI's dedication to environmental sustainability.
