Category Integrated Circuits (ICs) - Power Management (PMIC) - Hot Swap Controllers
Mfr Texas Instruments
Package Tube
Product Status Obsolete
Type Power Management
Applications General Purpose
Voltage - Supply 3V ~ 6V
Mounting Type Through Hole
Package / Case 16-DIP
Base Product Number UCC3918
Standard Package 25 pcs
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 693838-UCC3918N
Ultra Librarian 3D Model Ultra Librarian UCC3918N CAD Model

Description

The UCC3918N, manufactured by Texas Instruments, is a specialized integrated circuit designed to provide efficient power management solutions. This device is particularly targeted at applications requiring precise control and monitoring of the power supply, such as in telecommunications, industrial systems, and data acquisition units.

Key Features

  • Hot Swap Controller: The UCC3918N is equipped with hot swap capabilities, allowing electronic boards to be removed and inserted into live backplanes without causing damage or interruption to the running system.
  • Programmable Current Limit: It offers a programmable current limit feature that ensures the protection of the power supply and the load by preventing excessive current from flowing through the system.
  • Voltage Range: Operating within a wide voltage range, this device is versatile and suitable for various applications, accommodating different power requirements.
  • Charge Pump: The integrated charge pump circuitry allows for the control of external N-channel MOSFETs, which are used to regulate the power flow in the system.
  • Power Good Output: A 'power good' output signal is provided, which can be used to indicate whether the output voltage is within a specified range, ensuring reliable operation of the connected load.
  • Thermal Shutdown: The UCC3918N includes a thermal shutdown feature that protects the device from overheating, thereby enhancing the overall safety and longevity of the system.

Applications

The UCC3918N is ideal for a range of applications where power management and protection are critical. It is commonly used in server farms, network routers, and switches where hot swapping is a routine process. Additionally, it finds its place in industrial controls and robotic systems that require robust power control mechanisms to maintain operational integrity.

Package and Availability

This product is available in a PDIP (Plastic Dual In-line Package) form factor, ensuring ease of integration into a variety of circuit boards. Texas Instruments provides extensive support and documentation for the UCC3918N, making it a reliable choice for engineers and designers seeking a high-quality power management solution.
