Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Texas Instruments
Packaging Reel - TR
Part Status Obsolete(EOL)
Type Hot Plug Controller
Number of Channels 12
Internal Switch(s) Both
Applications PCI, PCI-X
Features Latched Fault, Thermal Limit, UVLO
Programmable Features Current Limit, Slew Rate
Operating Supply Voltage 1.5V, 3.3V, 5V, ±12V
Current - Output (Maximum) 100mA, 375mA, 500mA
Operating Temperature Range -40°C ~ 85°C
Mounting SMD
Package 80-TQFP Exposed Pad
Manufacturer Package 80-HTQFP (12x12)
Win Source Part Number 1272232-TPS2342PFPR
Manufacturer Homepage www.ti.com
Family Name TPS2342
Introduction Date January 01, 2005
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date Obsolete
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TPS2342PFPR CAD Model

Description

The TPS2342PFPR is a state-of-the-art power management integrated circuit (IC) designed and manufactured by Texas Instruments (TI), a leader in semiconductor solutions. This IC is specifically engineered to provide a high-efficiency, fast-response power supply for a wide range of applications.

Key Features

  • Versatile Power Management: The TPS2342PFPR offers a flexible and efficient power management system, suitable for a variety of devices including but not limited to, processors, FPGAs, and other digital ICs.
  • High Efficiency: With its advanced design, this IC ensures high efficiency in power conversion, which is crucial for maintaining the longevity of electronic components and reducing overall energy consumption.
  • Programmable Output Voltage: The device allows for a programmable output voltage, giving designers the flexibility to customize the power supply according to the requirements of the specific application.
  • Thermal Protection: It includes built-in thermal protection features that prevent the IC from overheating, thereby ensuring reliable operation under varying conditions.
  • Small Footprint: The TPS2342PFPR comes in a compact form factor, allowing for integration into systems where space is at a premium without sacrificing performance or functionality.

Applications

The versatility of the TPS2342PFPR makes it an ideal choice for a range of applications, including:

  • Networking Equipment
  • Telecommunications Infrastructure
  • Enterprise Computing
  • High-Performance Data Acquisition Systems
  • Industrial Controls

Technical Specifications

Parameter Value Input Voltage Range 1.1V to 5.5V Output Voltage Range 0.8V to 3.6V (Adjustable) Package QFP (Quad Flat Package) Thermal Protection Yes RoHS Compliant Yes

For more detailed information, datasheets, and support resources, customers are encouraged to visit the Texas Instruments official website or contact their local TI sales representative.
