The TUSB546-DCIRNQR is a high-performance, versatile USB Type-C Alternate Mode multiplexer/demultiplexer switch from Texas Instruments, designed to facilitate the management of different signal standards through a USB Type-C connector. This advanced component is an integral part of modern electronics, enabling the seamless transition between USB signals and other protocols such as DisplayPort and Thunderbolt.

Key Features

• USB Type-C Alternate Mode Support: The device supports USB Type-C Alternate Mode, allowing it to switch between USB 3.1 data signals and DisplayPort or Thunderbolt 3 signals.
• High-Speed Data Transfer: With the capability to handle USB 3.1 Gen 1 and Gen 2 data rates up to 10 Gbps, it ensures rapid data transfer and reduced wait times for end users.
• DisplayPort 1.4 Compatibility: The TUSB546-DCIRNQR supports the DisplayPort 1.4 standard, which includes features such as High Bit Rate 3 (HBR3) and High Dynamic Range (HDR) video.
• Bi-Directional Configuration: The switch can be configured in a bi-directional manner, enabling the multiplexing of both upstream and downstream signals.

Applications

The TUSB546-DCIRNQR is suitable for a wide range of applications, including:

• Notebooks and Desktop Computers
• Docking Stations
• Monitors and Displays
• USB Hubs and Peripherals

Technical Specifications

The device comes in a compact QFN package and operates over a broad temperature range, making it suitable for various environments and applications. Its low-power consumption and ESD protection features ensure reliability and longevity in any setup.

Manufacturer Support

Texas Instruments provides extensive support for the TUSB546-DCIRNQR, including detailed datasheets, application notes, and design resources to assist developers in integrating this switch into their products with ease.
