Product Overview: TS3USB221EDRCR by Texas Instruments

The TS3USB221EDRCR is a high-speed USB 2.0 (480 Mbps) 1:2 multiplexer-demultiplexer switch designed by Texas Instruments, which is a leader in the semiconductor industry. This product is particularly suitable for applications where efficient switching between two USB sources is required, such as in laptops, docking stations, and mobile devices.

Constructed with a high-bandwidth, low on-capacitance, and low on-resistance design, the TS3USB221EDRCR ensures minimal signal distortion and power loss, making it an excellent choice for maintaining signal integrity in high-speed data paths. The device's configuration allows one USB port to be shared between two devices, which can be particularly useful for saving space and reducing the number of USB ports required in a design.

Key Features

• High-Speed Performance: Supports USB 2.0 data rates up to 480 Mbps, ensuring compatibility with fast data transfer standards.
• Low Power Consumption: Designed for power efficiency, which is crucial for battery-powered devices.
• Bi-Directional Interface: Can route signals in both directions, offering flexibility in connecting USB peripherals.
• ESD Protection: Integrated electrostatic discharge (ESD) protection circuitry safeguards the device against damage from static electricity, enhancing its durability.
• Space-Saving: The compact SON (Small Outline No Lead) package allows for a minimal footprint on PCBs, optimizing space in portable electronics.

Applications

The TS3USB221EDRCR is ideal for a variety of applications that require efficient USB data routing, including:

• Personal Computers and Laptops
• Smartphones and Tablets
• USB Peripheral Devices
• USB Switching Hubs
• Docking Stations

With its combination of speed, efficiency, and compact design, the TS3USB221EDRCR from Texas Instruments represents a reliable solution for designers looking to optimize USB connectivity in their products. Its robust protection features and high-speed capabilities make it a versatile component in any modern electronic device requiring USB switching functionality.
