The TPS3813K33DBVRG4 is a state-of-the-art supervisory circuit designed and manufactured by Texas Instruments, a leader in semiconductor solutions. This device is specifically engineered to monitor voltage levels in microprocessor (µP) systems, digital systems, or other voltage-sensitive applications. Its primary function is to ensure that the system voltage remains within acceptable bounds, thereby providing a reliable safeguard against power failures or anomalies that could lead to system malfunctions or damage.

This supervisory circuit operates over a wide voltage range and features a fixed-sense threshold voltage of 3.3V, which is a common requirement for many digital systems. One of the key features of the TPS3813K33DBVRG4 is its precision voltage detection, which is critical for maintaining system stability and performance. The device boasts a low threshold voltage tolerance, ensuring accurate monitoring and response to voltage deviations.

The TPS3813K33DBVRG4 is equipped with a manual reset input, which provides a straightforward method for triggering a system reset. This feature allows for system recovery and maintenance without the need for complex procedures. Additionally, the device offers a reset delay time which can be programmed by an external capacitor, giving designers flexibility in how they manage system resets according to specific application requirements.

Packaged in a compact, 5-pin SOT-23 (DBVR) package, the TPS3813K33DBVRG4 is designed for space-constrained applications. Its small footprint makes it an ideal choice for portable devices, where size and power efficiency are of paramount importance. Furthermore, the device is characterized for operation over a temperature range of -40°C to 85°C, making it suitable for use in a wide range of environments and conditions.

Whether used in computing systems, portable electronics, or industrial equipment, the TPS3813K33DBVRG4 from Texas Instruments provides a reliable and precise voltage monitoring solution that enhances the overall stability and safety of electronic systems.
