Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Obsolete(EOL)
Type Hot Plug Controller
Number of Channels 12
Internal Switch(s) Both
Applications PCI, PCI-X
Features Latched Fault, Thermal Limit
Programmable Features Current Limit, Slew Rate
Supply Voltage - Operating 1.5V, 3.3V, 5V, ±12V
Current - Output (Max) 100mA, 375mA, 1.1A
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 80-HTSSOP
Win Source Part Number 055492-TPS2343DDPR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TPS2343DDPR CAD Model

Description

The TPS2343DDPR is a state-of-the-art power management integrated circuit (IC) developed by the renowned electronics company, Texas Instruments. This component is specifically designed to deliver efficient, reliable power distribution and management solutions for a wide range of applications, including but not limited to, servers, telecommunications, and networking equipment.

Key Features

  • High Efficiency: The TPS2343DDPR is engineered to provide high-efficiency power conversion, which helps to minimize energy loss and heat generation, thereby enhancing the overall performance and longevity of the end application.
  • Advanced Power Management: It comes with sophisticated power management capabilities that allow for seamless distribution of power among multiple subsystems, ensuring stable operation even under varying load conditions.
  • Programmable Flexibility: Users can program the device to meet specific power requirements, making it a versatile solution for a multitude of power supply configurations.
  • Hot Swap Capability: This IC supports hot swapping, enabling the replacement or addition of system components without the need to power down the entire system, which is crucial for mission-critical environments where downtime is not an option.

Technical Specifications

The TPS2343DDPR operates over a wide input voltage range and is designed to handle high current levels, which is essential for powering complex electronic systems. Its compact form factor, encapsulated in a PowerPAD™ package, allows for efficient thermal management and space-saving on the PCB.

Applications

Due to its robust design and versatile nature, the TPS2343DDPR is ideally suited for enterprise-level systems that require reliable power management. It is commonly used in:

  • Server Power Supplies
  • Telecommunication Equipment
  • Networking Hardware
  • Data Storage Systems

Conclusion

With its combination of high efficiency, advanced features, and programmable flexibility, the TPS2343DDPR from Texas Instruments represents a premier solution for modern power management challenges. Its ability to support hot swapping and handle demanding power requirements makes it an indispensable component in the development of reliable, high-performance electronic systems.
