Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Texas Instruments
Series Thunderbolt
Packaging Reel - TR
Switch Type General
Number of Outputs 2
Output Configuration High Side
Voltage - Load 2.8 V ~ 19.8 V
Rds On (Typ) 5 Ohm (Maximum), 250 mOhm (Maximum)
Fault Protection Reverse Current
Operating Temperature Range -40°C ~ 85°C (TA)
Package 16-XFBGA, DSBGA
Manufacturer Package 16-DSBGA (1.6x1.6)
Win Source Part Number 1272229-TPS22985YFPR
Manufacturer Homepage www.ti.com
Family Name TPS22985
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2028
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TPS22985YFPR CAD Model

Description

The TPS22985YFPR is a high-performance integrated circuit designed by Texas Instruments, known for its reliability and efficiency in power management applications. This device is a member of Texas Instruments' extensive range of power distribution switches designed for systems that require effective power distribution and control.

Key Features

  • Input Voltage Range: The TPS22985YFPR operates over a wide input voltage range from 0.8V to 5.5V, making it suitable for a variety of power rails commonly found in electronic systems.
  • Current Limiting: With an adjustable current limit feature, this switch can protect connected devices from excessive current draw, enhancing system safety and longevity.
  • Quick Output Discharge: The device incorporates a quick output discharge transistor, which ensures the output is rapidly discharged when the switch is turned off, preventing any unwanted voltage persistence.
  • Thermal Shutdown Protection: The TPS22985YFPR includes a thermal shutdown mechanism that prevents overheating, safeguarding the IC and the system during high-temperature conditions.
  • Ultra-Low On-Resistance: The on-resistance of this switch is remarkably low, which translates to reduced power loss and improved efficiency when conducting current.

Applications

The TPS22985YFPR is versatile and can be used in a wide array of applications, including but not limited to:

  • Smartphones and Tablets
  • Portable Electronics
  • Power Supply Control
  • Peripheral Ports

Package and Availability

The product is available in a compact, space-saving 6-pin package, identified by the YFP suffix in its part number. This makes it an ideal choice for portable and space-constrained applications. For ordering and pricing information, customers can visit the Texas Instruments website or contact authorized distributors.

Quality and Support

As with all Texas Instruments components, the TPS22985YFPR is manufactured to the highest quality standards and is backed by Texas Instruments' comprehensive technical support and documentation. Engineers and designers can rely on this product for their critical power management needs with confidence.
