TPS2113ADRBR

Part No TPS2113ADRBR
Manufacturer Texas Instruments
Catalog PMIC - OR Controllers, Ideal Diodes
Description IC OR CTRLR SRC SELECT 8SON / Pwr Mux Autoswitch 1.5V to 5.5V 2A 8-Pin VSON EP T/R
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Source Selector Switch
Polarity N-Channel
Internal Switch(s) Yes
Delay Time - ON 1ms
Delay Time - OFF 5ms
Current - Output (Max) 1.25A
Operating Supply Current 55μA
Supply Voltage - Operating 2.8 V to 5.5 V
Applications Handheld/Mobile Devices
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SON (3x3)
Win Source Part Number 376496-TPS2113ADRBR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name TPS2113A
Introduction Date October 01, 2009
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian TPS2113ADRBR CAD Model

Description

Product Overview: TPS2113ADRBR by Texas Instruments

The TPS2113ADRBR is a highly versatile power multiplexer component from Texas Instruments designed to manage power supply selection between two sources. This advanced integrated circuit (IC) is part of TI's extensive range of power management solutions, and it offers a seamless transition between two power sources in real-time, making it an excellent choice for multi-power systems.

Key Features

  • Automatic Switching: The TPS2113ADRBR automatically switches to the secondary power source when the primary source fails or is below the voltage threshold, ensuring a reliable power supply.
  • Wide Voltage Range: It can operate with input voltage ranges from 2.8V to 5.5V, accommodating a variety of power sources such as batteries, USB ports, and wall adapters.
  • Low RON: The device features a low on-resistance of typically 50 mΩ, which minimizes voltage drop and power loss across the switch.
  • Current Limiting: Built-in current limiting protects the device from over-current conditions, enhancing the safety and longevity of the power system.
  • Bidirectional Operation: The TPS2113ADRBR supports bidirectional switching, allowing it to manage power flow in both directions between the sources and the load.

Applications

The versatility of the TPS2113ADRBR makes it suitable for a wide range of applications, including:

  • Portable and battery-powered devices
  • Redundant power supply systems
  • Power supply failover and backup systems
  • USB-powered gadgets and peripherals

Package and Quality

The TPS2113ADRBR is offered in a compact QFN-8 package, ensuring a minimal footprint on the PCB and ease of integration into various designs. Texas Instruments is known for its commitment to quality, and this product is no exception, meeting high standards of performance and reliability.

With its robust feature set and the reputation of Texas Instruments behind it, the TPS2113ADRBR is an excellent choice for designers looking to create systems with reliable power supply selection and management.
