Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Type Source Selector Switch
FET Type N and P-Channel
Ratio - Input 2:1
Internal Switch(s) Yes
Current - Output (Max) 500mA, 100mA
Current - Supply 18 µA
Voltage - Supply 2.7V ~ 5.5V
Applications Handheld/Mobile Devices
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Case / Package 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package 8-SOIC
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1506144-TPS2105D
Ultra Librarian 3D Model Ultra Librarian TPS2105D CAD Model
