TPD1S514-2YZR - USB Charger Port Protection Device by Texas Instruments

The TPD1S514-2YZR from Texas Instruments is a highly integrated circuit designed to provide comprehensive protection for USB charger ports. This advanced protection device is specifically engineered to safeguard sensitive electronics against electrostatic discharge (ESD), over-voltage, and over-current conditions that are commonly encountered in USB charging applications.

Key Features:

• Integrated Protection: The TPD1S514-2YZR offers a 2-channel ESD solution, integrating IEC 61000-4-2 (Level 4) ESD protection, thus ensuring robust defense against electrostatic discharges.
• Over-Voltage Lockout (OVLO): The device includes an OVLO feature that turns off the path from VBUS to VOUT when the input voltage exceeds the over-voltage lockout threshold, preventing damage to downstream components.
• Over-Current Protection: With its built-in over-current protection, the TPD1S514-2YZR automatically disconnects the output during over-current events, safeguarding the USB port and connected devices.
• Thermal Shutdown: The thermal shutdown function enhances safety by turning off the device if the junction temperature exceeds a preset threshold, thereby preventing thermal runaway.
• Charger Detection Support: It supports USB Battery Charging Specification 1.2, which includes data line detection and charging port recognition, allowing for optimized charging compatibility.

Applications:

• Smartphones and Tablets
• USB Wall Chargers and Power Adapters
• USB Hubs and Docking Stations
• Portable Electronic Devices

The TPD1S514-2YZR comes in a small 1.5mm x 1.5mm, 6-pin YZP package, making it ideal for space-constrained applications. Its low capacitance ensures minimal signal degradation on data lines, while its high integration reduces component count and simplifies design. Whether it's for personal electronics or industrial-grade devices, the TPD1S514-2YZR offers a reliable and efficient solution for USB port protection.

With Texas Instruments' reputation for quality and performance, the TPD1S514-2YZR is an excellent choice for designers looking to enhance the durability and longevity of their USB charging solutions.
